RJ45 8P8C Female Splitter Adapter 1 to 2 Port Ethernet Connector

Name: RJ45 8P8C Female Splitter Adapter 1 to 2 Port Ethernet Connector
Brand: SHENZHEN JRKCONN ELECTRONICS CO.,LTD
SKU: JRK-RJ45-8P8C-1T2
Price: 0.07 USD
Availability: InStock

Product Details

Place of Origin: Guangdong, China

Brand Name: Jrkconn

Certification: ISO9001, ISO14001

Model Number: JRK-RJ45-8P8C-1T2

Payment & Shipping Terms

Minimum Order Quantity: Contact Us

Price: Contact us

Packaging Details: PE Bag Packaging

Delivery Time: 7-14 working days

Payment Terms: T/T,MoneyGram,D/P,D/A,L/C

Supply Ability: 10,000,000 per week

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                    8P8C Female Splitter Adapter, 1 to 2 Port Ethernet Connector, RJ45 Splitter Adapter


Product Type:	RJ45 Splitter Adapter	Interface:	1 Input / 2 Output
Number Of Ports:	1 Port	Color:	Black
Current Rating:	1.5A	Connection Type:	Straight Through

Product Type:	RJ45 Splitter Adapter
Interface:	1 Input / 2 Output
Number Of Ports:	1 Port
Color:	Black
Current Rating:	1.5A
Connection Type:	Straight Through

RJ45 8P8C Female Splitter Adapter 1 to 2 Port Ethernet Connector

Product Overview

The RJ45 8P8C splitter adapter is a compact network connector accessory designed to convert one RJ45 female interface into two RJ45 female ports. It provides a convenient solution for Ethernet connection extension, equipment testing, and network wiring applications.

With a straight-through connection structure and high-quality RJ45 female connectors, this adapter ensures stable signal transmission and reliable mechanical performance.

Applications

Ethernet network connection systems
Industrial Ethernet equipment
Communication devices
Network testing equipment
Data transmission systems
Smart devices and control systems
Computer networking accessories

Key Features

Dual RJ45 Female Port Design

Connector Type: RJ45 Female Jack
Interface Conversion: 1 Port to 2 Ports
Structure: Straight-through RJ45 adapter
Compatible with standard 8P8C Ethernet plugs

The dual-port design allows flexible connection between Ethernet cables and networking equipment, suitable for network accessories, industrial equipment, communication devices, and test applications.

Reliable Electrical Performance

Each RJ45 adapter undergoes electrical performance testing to ensure connection reliability.

Open Circuit Test: Passed
Short Circuit Test: Passed
Electrical Performance Inspection: 200% testing completed

This inspection process helps ensure stable contact performance before shipment.

Flexible Gold Plating Options

The contact mating area supports various gold plating thickness options:

Gold Flash
0.8μinch
1μinch
1.5μinch
3μinch
6μinch
15μinch
30μinch
50μinch

Different plating thicknesses can be selected according to application requirements, mating cycles, and cost considerations.

Wide Operating Temperature Range

Available operating temperature options:

0°C to +85°C
-40°C to +85°C

Storage Temperature: -40°C to +85°C

Suitable for indoor networking equipment and industrial environments requiring stable temperature performance.

RoHS & REACH Compliance

The RJ45 8P8C splitter adapter complies with:

RoHS environmental requirements
REACH regulations

The product meets international environmental compliance standards for global markets.

Why Choose JRKCONN?

Competitive pricing with stable production and fast delivery
Strict quality control and 100% inspection before shipment
Support for bulk orders and quick lead times
OEM/ODM support for cable assembly and special requirements
Fast response, global shipping support, and technical assistance

Product Specifications

Specification	Value	Specification	Value
Model number	JRK-RJ45-8P8C-1T2	Working Temperature	-40°C to +85°C
Interface	1 Input / 2 Output	Standard	UL 1061
Port Type	8P8C	RoHS Compliance	Yes
Shielding	Unshielded (Without Metal Shield)	REACH Compliance	Yes
Contact Plating	Gold Flash / 0.8u" / 1u" / 1.5u" / 3u" / 6u" / 15u" / 30u" / 50u"	Quality Assurance	200% Electrical Performance Testing
Material:
Housing	ABS, UL94V-0	Terminal	Phosphor Bronze, Gold Flash on Contact Area
Mechanical:
Durability	750 Cycles Min, 12.5MM/Minute	Storage Temperature	-40°C to +85°C
Electrical:
Voltage	125V/AC	Current Rating	1.5 Amp
Dielectric Strength	1000V/AC RMS 50 Hz or 60 Hz. 1Min.	Insulation Resistance	500 Mega Ohms Min 500V/DC
Contact Resistance	300 Milliohms Max.

Packing & Delivery

Selling Units	Package	Port
Single item	PE bag + carton box packing	Shenzhen

Shipping options: Air freight, sea freight, or express courier (DHL, FedEx, UPS)

Quantity (pcs)	Samples	Estimated delivery time (business days)
one to one hundred thousand	3 ~ 7	15
> 100K	To be negotiated

Custom Manufacturing Process

Dimensions

Frequently Asked Questions

Q1. Can I have a sample order for the terminal blocks before placing a purchase order?

A: Of course, samples are available for testing, and customers pay only the express courier cost.

Q2. What is the sample lead time?

A: Standard samples will take 3 - 7 working days. Customized samples take 7-15 working days.

Q3. Do you have any MOQ Limit?

A: Low MOQ; 1 piece for sample checking is available.

Q4. Can I make personalized/customized products?

A: Yes, we accept custom orders based on your drawings or samples.

Q5. How do you ship the goods and how long will it take to ship to my country?

A: We usually ship by DHL, UPS, FedEx, TNT, or by the customer's appointed freight forwarder. It usually takes 3 - 7 days to arrive.
