Name: 3.81mm Pitch 8 Poles PCB Screw Terminal Block Green Wire Terminals
Brand: SHENZHEN JRKCONN ELECTRONICS CO.,LTD
SKU: JRK15EDGKRP
Price: 0.07 USD
Availability: InStock

Product Details

Place of Origin: Guangdong, China

Brand Name: Jrkconn

Certification: ISO9001

Model Number: JRK15EDGKRP

Payment & Shipping Terms

Minimum Order Quantity: Contact Us

Price: Contact us

Packaging Details: PE Bag Packaging

Delivery Time: 7-14 working days

Payment Terms: T/T,MoneyGram,D/P,D/A,L/C

Supply Ability: 1000000 per week

Get Best Price

Chat Now

Product Details

Product Description

Highlight:
                                                                                                                                                                                    3.81mm Pitch PCB Screw Terminal Block, 8 Poles Pluggable Terminal Block, 28-16 AWG Wire Terminal


Pitch:	3.81mm	Poles:	2-24P Available
Color:	Green, Terminal Block's Color Can Be Customized	Screw:	Steel,M2.0 Steel Zinc Plated
Wire Gauge:	28-16 AWG	Torque:	0.2Nm(1.7Lbin)

Pitch:	3.81mm
Poles:	2-24P Available
Color:	Green, Terminal Block's Color Can Be Customized
Screw:	Steel,M2.0 Steel Zinc Plated
Wire Gauge:	28-16 AWG
Torque:	0.2Nm(1.7Lbin)

3.81mm Pitch 8 Poles PCB Screw Terminal Block Green Wire Terminals

3.81mm PCB Screw Terminal Block 8 Poles Female Green Wire Terminals

High-quality PCB pluggable terminal blocks designed for 28-16AWG wire gauge with superior connectivity and reliability for industrial applications.

Key Advantages of Plug-in Terminal Blocks

Direct insertion spring connection design enables fast and efficient wiring
Dual-side locking mechanism provides easier operation and improved space efficiency
Automatic plug-and-lock function prevents accidental disconnection during operation
Integrated stainless steel auxiliary clamps maintain long-term connection stability under temperature variation

Why Choose JRKCONN?

Over 13 years of specialized experience in terminal block production with deep industry knowledge
Strict 100% inspection policy for all products before shipment
Comprehensive service from sourcing and design support to final delivery
Professional technical support and custom technical drawing assistance

Product Specifications

Model Number	JRK15EDGKRP-3.81
Type	Pluggable Terminal Block Connector
Pitch	3.81mm
Poles	2P-22P
Screws Material	M2.0 Steel, Zinc Plating
Contact Material	Phosphor Bronze, Ni Plating
Wire Cage/Wire Guard	Brass, Tin plating
Housing Material	PA66, UL94V-0
Rated Voltage	300V
Withstanding Voltage	AC 1600V / 1Min
Rated Current	8A
Wire Range	28-16 AWG
Temperature Range	-40℃ ~ +105℃
Strip Length	6-7 mm
Max Soldering	+250℃ for 5 Seconds
Torque	0.2Nm(1.7Lbin)
Color	Green
Application	Aerospace, Rail Transportation, Shipbuilding, Machinery, Metallurgical Chemical, Power Communication, Electrical Control, etc

Note: The actual product color may vary slightly from images due to monitor settings. All measurements are taken manually and may have slight deviations.

Technical Drawing

Packaging & Delivery

Quantity (PCS)	Estimated delivery time (business day)
Selling Units	Single item
Package	PE bag + carton box packing
Port	Shenzhen
Samples	3-7
1-50K	7-14
51K-100K	15-20

Custom Manufacturing Process

Frequently Asked Questions

Q1. Can I have a sample order before placing a purchase order?

Samples are available for testing; customers pay only the express courier cost.

Q2. What is the sample lead time?

Standard samples take 3-7 working days; customized samples take 7-15 working days.

Q3. Do you have any MOQ Limit?

Low MOQ available; 1 piece for sample checking.

Q4. Can I make personalized/customized products?

Yes, we accept custom orders based on your drawings or samples.

Q5. How do you ship the goods, and how long does it take?

We ship via DHL, UPS, FedEx, TNT, or your freight forwarder, typically arriving in 3-7 days.
