Highlight:
PBT smt header
, female to female header connector
, 2X5P Female Pcb Connector
PBT SMT Header Female Header Connectors 2X5P Female Pcb Connector
3.96 Mm Pitch SMT Type Female Header Connectors 2X5P Female Pcb Connector
3.96 Mm Pitch SMT Type Female Header Connectors 2X5P Female Pcb Connector Specifications
| Insulator Material |
Black Polyester UL94V-0 |
| Contact |
Phosphor Bronze |
| Pitch |
1.27MM / 2.0MM / 2.54MM/ 3.96MM, support custom |
| No. Of Positions |
According to the customer's request |
| Plating |
Gold plating, Tin plating |
| Rated Current |
7A |
| Insulator Resistance |
1000 mΩ |
| Contact Resistance |
20 mΩ |
| Withstanding Voltage |
550V AC / minute |
| Operating Temperature |
Gold plating: from -55℃ to +105℃, Tin plating: from -40℃ to 105℃ |
| Soldering Temperature |
245℃,10s max. |
3.96 Mm Pitch SMT Type Female Header Connectors 2X5P Female Pcb Connector Packing & Delivery
Packing:
| Selling units |
Single item |
| Package |
Tube / PE bag/ tray / tap&reel packing |
| Port |
Shenzhen |
Delivery:
| Quantity (pcs) |
1 - 100K |
> 100K |
Estimated delivery time
(business day) |
15 |
To be negotiated
|
3.96 Mm Pitch SMT Type Female Header Connectors 2X5P Female Pcb Connector Custom Process
How To Choose Female Header Connectors:
You should tell us the following information:
1. The pitch of the product, e.g., 1.27 mm, 2.0mm, 2.54mm, 3.96mm, or special pitch.
2. The material of the insulators, the terminals, and the contact clips.
3. The plating of the terminals and the contact clips that you want. The standard is gold plating, tin plating, and gold/tin plating.
4. Your order quantity and your requirements.
5. Customized service is available.
Why Choose Jrkconn:
1. Good quality control.
2. Highly competitive prices.
3. State-of-the-art technology products.
4. Best professional team of lifestyle consumer electronics.
5. Smooth communication.
6. Effective OEM&ODM service.
FAQ
1. Are you a manufacturer or trade company?
We are a professional manufacturer with 15 years of experience specializing in electronic connectors. Our main products are pin headers, female headers, box headers, ejector headers, DIN41612 connectors, pins, and other electronic connectors, with good quality and competitive prices.
2. Can I get the sample before placing a purchase order?
Yes, we provide the samples for our customers to check the quality of the product.
We recommend our customers take the samples from us before placing an order. This will help customers to understand our product and quality better.
For 1 or 2 pieces of samples they are free, and customers only pay the express courier cost.
3. What is the sample lead time?
The standard sample delivery date is about 3~5 working days, and the customized samples need 7~10 working days.
4. What is your after-sales service?
If a customer finds a quality problem, please feel free to contact us and we will study the problem and provide solutions as fast as we can.
